Garrett GT3582R Supercore (w/ Ported Shroud) - REWRK Collective
Garrett

Garrett GT3582R Supercore (w/ Ported Shroud)

In stock
SKU: 836033-5002S
$1,381.80

Product details

  • SKU 836033-5002S
Description

HP: 400-675              Disp: 2.0L-4.5L



Compressor

Inducer 61mm

Exducer 82mm

Trim 56

A/R 0.70



Turbine

Inducer 68mm

Exducer 62mm

Trim 84



Interchangeable with GT, GTX Gen I, and GTX Gen II 35 Series Supercores Turbine Kits:






740902-0011 0.82 T3 V-Band

740902-0010 1.06 T3 V-Band
740902-0018 0.63 T4 V-Band
740902-0017 0.82 T4 V-Band
740902-0016 1.06 T4 V-Band
740902-0012 0.63 T3 V-Band
740902-0033 0.61 V-Band V-Band
740902-0032 0.83 V-Band V-Band
740902-0031 1.01 V-Band V-Band





Compressor Map



Exhaust Flow ChartFlange Diagram
Speed Sensor Installation Instruction
