Garrett Gen2 GTX2867R RB26DETT Twin Turbo Drop-In Upgrade

In stock
SKU: 849894-5001S
Regular price $4,495.00

Product details

  • SKU 849894-5001S

Description:

Garrett GEN2 GTX2860R dual ball bearing Twin Turbochargers are a complete, bolt-on package fit for the Nissan Skyline GT-R RB26DETT. The package is capable of supporting up to 900HP in a twin turbo configuration, and includes two turbochargers along with O2 housings/dump pipes for stock flange exhaust manifolds.

Product Features:
  • Advanced aerodynamics & ultra high flow Garrett GTX GEN2 compressor wheel
  • Forged billet aluminum compressor wheel
  • Dual ball bearing CHRA rotating assembly
  • Bolt-on for Nissan RB26DETT motor
Product Specifications:
  • Compressor Wheel Inducer: 46mm
  • Compressor Wheel Exducer: 60mm
  • Compressor Wheel Trim: 58
  • Compressor Housing: 0.60 A/R, RB26DETT Style 2 bolt inlet flange and 2 bolt outlet flange
  • Turbine Wheel Inducer: 54mm
  • Turbine Wheel Exducer: 47mm
  • Turbine Wheel Trim: 76
  • Turbine Housing: 0.64 A/R, T25 Inlet, Internal Wastegate Design, and RB26DETT Specific 5 Bolt Outlet
  • Internal Wastegate Actuator: 14PSI
Applicable Garrett Part Numbers:
  • 849894-5001S
